8-4
User's Manual
OPTIONAL DEVICES
Removing a PC card
To remove the PC card, follow the steps below.
1. Push the eject button and release it to extend the button.
2. Press the extended eject button to pop the card out slightly.
3. Grasp the card and pull it out.
Figure 8-3 Removing the PC card
4. Insert the dummy card. Press gently to ensure a firm connection, but do not
force the card into position. Do not leave the PC card slot empty.
Figure 8-4 Inserting the dummy card
DUMMY CARD
EJECT BUTTON
PC CARD
To Next Page
