Toshiba B-EP2DL Series Maintenance Manual

2. MAJOR UNIT REPLACEMENT EO18-33024
2.1 Replacing the CPU PC Board
2-2
4) Press the Top Cover Open Button to open the Top Cover.
5) Remove the Left Side Cover in the direction of the arrow.
6) Remove the Right Side Cover and the Front Cover in the direction of the arrow, respectively.
NOTE: The Gears shown in the picture below are not secured and are easily removed. Be carefu
l
not to drop and break or lose them.
Top Cover
Top Cover Open Button
Left Side Cover
Gear
Right Side Cover
Front Cove
r
