EO10-33024
TABLE OF CONTENTS
Page
1. OUTLINE -------------------------------------------------------------------------------------------------1- 1
1.1 PRINTER SPECIFICATIONS---------------------------------------------------------------------------1- 1
1.2 DESCRIPTION OF MODEL NUMBER ---------------------------------------------------------------1- 1
1.3 APPEARANCE AND DIMENTIONS (APPROXIMATE) -----------------------------------------1- 2
1.4 BASIC SPECIFICATIONS ------------------------------------------------------------------------------- 1- 4
1.5 ELECTRONICS SPECIFICATIONS-------------------------------------------------------------------1- 7
2. SUPPLY SPECIFICATIONS-------------------------------------------------------------------------2- 1
2.1 MEDIA --------------------------------------------------------------------------------------------------------2- 1
2.2 RIBBON ------------------------------------------------------------------------------------------------------2- 8
2.3 CARE AND HANDLING OF THE MEDIA AND RIBBON ----------------------------------------2- 5
2.4 SPECIFICATION OF RFID TAG(for B-EX700-RFID-H1-QM-R) --------------------------- 2- 10
2.5 SPECIFICATION OF RFID TAG(for B-EX700-RFID-U2-EU-R) ---------------------------- 2- 14
2.6 SPECIFICATION OF RFID TAG(for B-EX700-RFID-U2-US-R) ---------------------------- 2- 19
2.7 SPECIFICATION OF RFID TAG(for B-EX700-RFID-U2-CN-R)---------------------------- 2- 25
3. OPTIONAL KIT -----------------------------------------------------------------------------------------3- 1
3.1 CUTTER MODULE: B-EX204-QM-R (Disk Cutter), B-EX204-R-QM (Rotary Cutter) ----3- 2
3.2 PEEL MODULE: B-EX904-H-QM-R ------------------------------------------------------------------3- 3
3.3 RIBBON SAVING MODULE: B-EX904-R-QM-R --------------------------------------------------3- 3
3.4 EXPASION I/O CARD: B-EX700-IO-QM-R----------------------------------------------------------3- 6
3.5 RTC/USB host INTERFACE BOARD: B-EX700-RTC-QM-R -----------------------------------3- 6
3.6 RFID MODULE: B-EX700-RFID-H1-QM-R----------------------------------------------------------3- 6
3.7 RFID MODULE: B-EX700-RFID-U2-EU/US/CN-R ------------------------------------------------3- 7
3.8 Wireless LAN BOARD: B-EX700-WLAN-QM-R----------------------------------------------------3- 9
CAUTION!
1. This manual may not be copied in whole or in part without prior written permission of TOSHIBA
TEC.
2. The contents of this manual may be changed without notification.
3. Please refer to your local Authorised Service representative with regard to any queries you
may have in this manual.
Copyright © 2011
by TOSHIBA TEC CORPORATION
All Rights Reserved
570 Ohito, Izunokuni-shi, Shizuoka-ken, JAPAN
This manual is intended for both B-SX4T series and B-SX5T series. Please note that the
illustrations and pictures provided are of the B-SX4T series.
The SP40II has been developed from the B-SX4T-GS10-QP, and the differences between
two are the color of the front cover and the operation panel ass’y, the model name label, and
the CD-ROM. The other specifications including the firmware are common.
