Toshiba B-EX4 T1 Series User Manual

TABLE OF CONTENTS
Page
1. OUTLINE -------------------------------------------------------------------------------------------------1- 1
1.1 PRINTER SPECIFICATIONS --------------------------------------------------------------------------- 1- 1
1.2 DESCRIPTION OF MODEL NUMBER --------------------------------------------------------------- 1- 1
1.3 APPEARANCE AND DIMENTIONS (APPROXIMATE) -----------------------------------------1- 2
1.4 BASIC SPECIFICATIONS ------------------------------------------------------------------------------- 1- 4
1.5 ELECTRONICS SPECIFICATIONS------------------------------------------------------------------- 1- 9
2. SUPPLY SPECIFICATIONS-------------------------------------------------------------------------2- 1
2.1 MEDIA (Paper)----------------------------------------------------------------------------------------------2- 1
2.2 RIBBON ---------------------------------------------------------------------------------------------------- 2- 11
2.3 CARE AND HANDLING OF THE MEDIA AND RIBBON -------------------------------------- 2- 15
2.4 PRINT CONDITIONS ----------------------------------------------------------------------------------- 2- 16
2.5 SPECIFICATION OF RFID TAG (for B-EX700-RFID-H1-QM-R) --------------------------- 2- 18
2.6 SPECIFICATION OF RFID TAG (for B-EX700-RFID-U2-EU-R) ---------------------------- 2- 21
2.7 SPECIFICATION OF RFID TAG (for B-EX700-RFID-U2-US-R) ---------------------------- 2- 25
2.8 SPECIFICATION OF RFID TAG (for B-EX700-RFID-U2-CN-R) ---------------------------- 2- 29
3. OPTIONAL KIT -----------------------------------------------------------------------------------------3- 1
3.1 CUTTER MODULE: B-EX204-QM-R (Disk Cutter), ----------------------------------------------- 3- 2
3.2 PEEL MODULE: B-EX904-H-QM-R ------------------------------------------------------------------ 3- 3
3.3 EXPASION I/O CARD: B-EX700-IO-QM-R---------------------------------------------------------- 3- 5
3.4 RTC/USB host INTERFACE BOARD: B-EX700-RTC-QM-R -----------------------------------3- 5
3.5 RFID MODULE: B-EX700-RFID-H1-QM-R---------------------------------------------------------- 3- 5
3.6 RFID MODULE: B-EX700-RFID-U2-EU/US/CN-R ------------------------------------------------3- 6
3.7 WIRELESS LAN BOARD: B-EX700-WLAN-QM-R ------------------------------------------------ 3- 8
CAUTION!
1. This manual may not be copied in whole or in part without prior written permission of TOSHIBA
TEC.
2. The contents of this manual may be changed without notification.
3. Please refer to your local Authorised Service representative with regard to any queries you
may have in this manual.
Copyright © 2011-2012
by TOSHIBA TEC CORPORATION
A
ll Rights Reserved
570 Ohito, Izunokuni-shi, Shizuoka-ken, JAPAN

Toshiba B-EX4 T1 Series Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Resolution	203 dpi, 300 dpi, 600 dpi
Max Print Width	4.09 inches (104 mm)
Media Type	Roll, Fanfold
Connectivity	USB 2.0, Ethernet
Optional Interfaces	Wireless LAN
Media Thickness	0.06 mm to 0.17 mm
Ribbon Width	40 – 110 mm
Barcodes	Code 39, Code 128, UPC/EAN/JAN, Postnet
2D Codes	Data Matrix, PDF417, QR Code, MaxiCode
