e-STUDIO2040C/2540C/3040C/3540C/4540C © 2011 TOSHIBA TEC CORPORATION All rights reserved
2 - 78
2. Copier-specific Adjustments
2.18.2 To Adjust Custom Mode Settings in Full Color Mode
* All the steps in the adjustment procedure shall be performed by the service technician.
(1) Enter the setting mode [08]. Change the value for the code [7614] to enable the functions of the custom
mode in the full color mode.
Value for 08-7614 User mode for full color mode
0 Unused
1 Used (Text/Photo base)
2 Used (Text base)
3 Used (Printed Image base)
4 Used (Photo base)
5 Used (Map base)
* The default adjustment value for the custom mode is preset at the one that reproduces the image quality
equivalent to that of Text/Photo in the full color mode at the time of shipment.
After setting the value, go to the next step.
(2) Enter the adjustment mode [05]. Adjust each setting value for the custom mode to satisfy the user’s request.
• Select the necessary adjustments from the procedures below.
To make background lighter
(a) Enter the adjustment mode [05]. Decrease the values for codes [7661] to make the background
lighter.
Color mode
Density
mode
[05] code
Recommended
value
Acceptable
range value
Default
Automatic
Full color
Manual
05-7661 Set 127 or smaller. 0 to 255 128
* Set the value in increments of approximately 10, while checking the copy image until the optimum
value is obtained.
(b) To make another adjustment of the background for Full color after the above adjustment, enter the
adjustment mode [05] and then increase the values for codes [7762/7763] to make the background
lighter.
Color mode
Density
mode
[05] code
Recommended
value
Acceptable
range value
Default
Automatic 05-7762
Full color
Manual 05-7763
Set 128 or larger. 0 to 255 128
* Adjust the density level while checking the color balance since it may differ from that of the
original after the adjustment.
* Set the value in increments of approximately 10, while checking the copy image until the optimum
value is obtained.
To Next Page
