Toshiba e-STUDIO6550C Series Troubleshooting Guide

1.TROUBLESHOOTING FOR THE HARDWARE
Clearing a Paper Jam 17
1 TROUBLESHOOTING FOR THE HARDWARE
 Paper jam in the Reversing Automatic Document Feeder (optional) (Upper)
1
Raise the lever and open the upper cover.
2
Remove the original.
3
Turn the inner green dial and remove the jammed
original.
4
Raise the green lever and open the transport guide.
5
Raise the guide plate under the transport guide, and
remove the original under the guide plate.
2
1
