1 TROUBLESHOOTING FOR THE HARDWARE
26 Clearing a Paper Jam
Paper jam in the Job Separator and the Offset Tray (both optional)
The procedure below is only for e-STUDIO206L/256/306 with the Job Separator or the Offset Tray installed and not valid
for e-STUDIO356/456 with the Job Separator installed.
y Be careful not to let your fingers be caught between the equipment and the duplexing unit or automatic
duplexing unit.
This could injure you.
y Do not touch the fuser unit or the metal portion around it.
Since they are very hot, you could be burned or the shock could cause you to get your hand injured in the machine.
4
Close the cover inside of the equipment.
5
Close the automatic duplexing unit.
1
Open the automatic duplexing unit on the right.
2
Open the cover inside of the equipment.
3
Remove the jammed paper.
To Next Page
