86 P9 ASD Installation and Operation Manual
Automatic Function Selection
Program Utilities Display Parameters
This parameter setting is used to configure multiple parameters with the setting
of only one parameter. From the selection below, multiple parameters may be
set as indicated in the table.
Once set, the selected configuration is placed in effect and remains in effect
until this parameter is changed or the individual settings are changed.
Set this parameter to Disable to set these parameters individually.
Note: After performing the desired selection, the EOI display returns to
Disabled though the selected function has been carried out (i.e.,
without this, if selection 1 is performed, F004 and F207 would
hold the RR terminal setting regardless of attempts to change the
settings individually).
Settings:
0 — Disabled
1 — RR
2 — V/I
3 — RR or V/I (V/I) Switched via Terminal Board
4 — Keypad = Frequency/Terminal Board = Command
5 — Keypad = Frequency and Command
Direct Access Number — F040
Parameter Type — Selection List
Factory Default — Disabled
Changeable During Run — No
User Settings
0 1 2 3 4 5
Related
Parameters
Default
Settings
Disabled RR V/I
RR or V/I
via TB
Keypad/
Freq.
CMD/TB
Keypad
Freq/CMD
Command
Mode
F003
Terminal
Board
N/C
Terminal
Board
Keypad
Frequency
Mode 1
F004
RR N/C RR N/C RR Keypad
S3 Terminal
F117
Preset
Speed 3
N/C
Freq. Ref.
Priority
N/C
Frequency
Priority
F200
Terminal
Board
N/C Terminal Board
V/I Setup
F201
0.0% N/C 20.0% N/C
Frequency
Mode 2
F207
V/I N/C RR V/I Keypad
N/C = No Change — the setting remains as it was before setting parameter F040.
F040 F040
