6F3B0253
Basic Hardware and Function
15
1. System Configuration
Memory capacity:
Program memory capacity of the T1 is 2 k steps. And that of the T1S is 8 k steps.
Whole the program and a part of data registers are stored in built-in EEPROM.
T1-16/28/40 T1-40S
T1-16S
Memory
RAM (for execution) and EEPROM (for back-up)
Program
capacity
2 k steps 8 k steps
(4 k mode or 8 k mode)
Data capacity
Auxiliary relay: 1024 points
Timer: 64 points
Counter: 64 points
Data register: 1024 words
Auxiliary relay: 4096 points
Timer: 256 points
Counter: 256 points
Data register: 4096 words
EEPROM
back-up
Program and leading 512
words of Data register
Program and the user specified range of
Data register (0 to 2048 words)
Capacitor: 1 hour
or more
RAM back-up
(at 25°C)
(at 77°F)
Capacitor: 6 hours or more Capacitor: 168 hours
or more
Battery: 2 years
or more
Control functions:
In addition to the basic relay ladder functions, the T1/T1S provides functions such as
data operations, arithmetic operations, various functions, etc. Furthermore, its high-
speed counter functions, pulse output functions and data communication functions
allow its application to a wide scope of control systems.
T1-16/28/40 T1-40S
T1-16S
Language
Ladder diagram with function block
Number of
instructions
Basic: 17 types
Function: 76 types
Basic: 21 types
Function: 99 types
Basic: 21 types
Function: 97 types
Subroutines
16
(nesting not allowed)
256
(up to 3 levels of nesting)
Execution speed
1.4 µs/contact, 2.3 µs/coil, 4.2 µs/transfer, 6.5 µs/addition
Real-time
clock/calendar
No Yes (year, month, day, week, hours,
minutes, seconds)
Communication
RS-232C
(programmer port)
RS-232C (programmer port),
RS-485 (multi-purpose)
Construction:
The T1-16S is a compact, easy-handling block style programmable controller. The
T1-16S has all of the features of a block style controller. In addition, the T1-16S has
modular expandability. The T1-16S provides flexibility into the block style controller.
Series compatibility:
Programming instructions are upward compatible in the T-Series programmable
controllers. The T1/T1S programs can be used for other models of the T-Series, T2,
T2E, T2N, T3 and T3H. Peripheral tools can also be shared.
