Toshiba PROSEC T1-16S - Page 43

6F3B0253
Basic Hardware and Function 41
2. Specifications
Functional specifications (cont’d)
Item T1-16S
I/O capacity 16 points (basic)
+128 points (I/O modules)
Input 24Vdc input (8 points)I/O type
Output Relay (6 points) + transistor (2 points)
I/O terminal block Fixed
Real-time clock
/calendar
Yes, ±60 s/month at 25°C
(Enhanced model only)
Special I/O functions
(Note)
• High speed counter, 2 single or 1 quadrature
• Interrupt input, 2 points
• Adjustable analog register, 2 points
• Pulse output, CW+CCW or pulse+direction
• PWM output
Communications
interface
• 1 port RS-232C (programmer port)
- for Programmer or Computer link connection
• 1 port RS-485 (Enhanced model only)
- Programmer
- Computer link
- Data link
- Free ASCII
• TOSLINE-F10 remote (by I/O module)
Debug support
function
• Sampling trace, 8 devices and 3 register - 256 times
• On-line programming
• On-line EEPROM write
(1) High-speed counter, interrupt input, pulse output and PWM output are
available in the DC input types.
(2) High-speed counter and interrupt input cannot be used simultaneously.
(3) Pulse output and PWM output cannot be used simultaneously.
