Toshiba TE2 Series - Fault History, Phase, and Power Protection

TE2 Series Digital Solid State Soft Starter User Manual 36 | Page
5.5.15 Motor Power Protection Settings
5.5.16 Analog Output
5.5.17 Display and System Settings
Fn # Group Function Description Adjustment / Display Range
Setting
Increments
Factory
Setting
Section
F102
Power Protection
Motor kW Trip
0 - 2
0 = Disabled
1 = Over kW Trip
2 = Under kW Trip
1 0
5.6.15
F103 Motor kW Trip Point 20 - 100% of full load KW 1% 50(%)
F104 Motor kW Trip Delay Time 1 - 999 seconds 1 1
F105 Power Factor Trip Range
0, 1 - 3 [0=Disabled, 1=lag, 2=lead,
3= lead/lag]
1 0
F106 Power Factor Trip Point .01 - 1 .01 .50
F107 Power Factor Trip Delay Time 1 - 20 seconds 1 2
Table 5.5.15: Motor Power Protection Function Group
Fn # Group Function Description Adjustment / Display Range
Setting
Increments
Factory
Setting
Section
F108
Power Protection
Analog Output
0 - 12
[0: OFF; 1 - 12]
(See Table of Default Display)
1 OFF
5.6.16
F109 Analog Output 4mA 0 - 9999 1 0
F110 Analog Output 20mA 0 - 9999 1 9999
Table 5.5.16: Analog Output
Fn # Group Function Description Adjustment / Display Range
Setting
Increments
Factory
Setting
Section
F111
System Settings
Default Display 1-12 (See Table of Default Display) 1 10
5.6.17
F112 System Settings Reserved for factory use - -
F113
Alternate functions for
Ramp2/Jog inputs
See Table page 64 1 7
Table 5.5.17: System Settings
