TE2 Series Digital Solid State Soft Starter User Manual 62 | Page
F106 = Motor Power Factor Trip Point
Factory Setting = 0.50 (cosine θ)
Range = 0.01 - 1.0 measured motor Power Factor
Motor Power Factor (PF) is measured based upon measured
voltage and current waveforms.
F107 = Motor Power Factor Trip Delay Time
Factory Setting = 2 seconds
Range = 1 - 20 seconds
Provides a time delay to prevent nuisance trips from short-
duration transients. Using default setting, if the motor PF moves
outside of the settings in F106 in the direction set in F105 for
more than 2 seconds, the starter will trip.
5.6.16 Analog Output
F108 = Analog Output
Factory Setting = 0 (Off)
Range = 1 - 12
Sets analog output signal
Value Display Definition
1
XXXX. (A) or
XX.XX. (kA)
Ia: Phase A Current (With a dot “.” Shown at bottom
right corner of rightmost digit.)
Shows XX.XX if Iavg>9999 Amp. e.g.12.50
means12.5kA.
2
XXXX (A) or
XX.XX (kA)
Ib: Phase B Current
Shows XX.XX if Iavg>9999 Amp.
3
XXXX (A) or
XX.XX (kA)
Ic: Phase C Current
Shows XX.XX if Iavg>9999 Amp.
4
GXXX Igf: Ground Fault Current
5
UXXX Uab: Line Voltage AB
6
UXXX Ubc: Line Voltage BC
7
UXXX Uca: Line Voltage CA
8
L
XXX (
L
is like superscript) or
L
XXX (
L
is like subscript)
Power Factor (a superscript “L” is for Lead condition, or
subscript “L” for Lag. Either of them is shown at leftmost
digit)
9
PXXX
KW (w/o decimal point) or MW (w/ decimal point):
Kilo-watt (range: 000 - 999);
Mega-watt (range: 0.00 - 9.99)
10
XXXX (A) or
XX.XX (kA)
Iavg: Average of 3 Phase Currents (It is factory default
display);
Shows XX.XX if Iavg>9999 Amp.
11
UXXX Uavg: Average of 3 Line Voltages
12
HXXX Thermal Capacity Remaining
