Toshiba TOSVERT VF-MB1 Function Manual

E6581818
- 6 -
2. Names and functions
The drawing below shows names and functions of main parts.
2.1. Outline
Shielded female RJ45
Ethernet Connector
(Port IN)
LED indicator (See 2.3)
Shielded female RJ45
Ethernet Connector
(Port OUT)
Connector to the inverter
Release tab
ERR
X2 L/A
RUN
L/A X1
X1 means EtherCAT IN port,
X2 means EtherCAT OUT port
