Total Source 161TA6945 - Main Components of the Product; Placement of the Decals

10/68
2.2. Main components of the product
2.3. Placement of the decals
The safety and warning labels should be placed as described in the pictures below.
Seechapter3 for the explanation of the safety warnings. If the decals are damaged or
missing, replace them.
1
4
2
3
5
6
7
4
13
5
6
7
1
12
2
3
8
9
8
11
10
N° Component
1 Cylinder
2 Hydraulic hoses
3 Control panel
4 ON/OFF button
5 Pressure gauge
6 Hydraulic pump unit
7 Electrical equipment box
N° Component
8 Safety decals
9 Electric motor
10 Mounting holes
11 Fork pockets
12 Pressure plate
13 Type plate
1
12
3
4
13
14
11
2
5
6
7
8
9
10
