2. DESCRIPTION
2.1. Technical data
Always check the type plate for the correct information.
161TA6945
Type TP120
Capacity (kg) 120000
Max tyre dimension (mm) 1000x20
Total length (mm) 2080
Total width (mm) 850
Total height (mm) 2151
Operating pressure (bar) 230
Cylinder stroke (mm) 400
Oil tank capacity (L) 30
Electric motor power (kW) 7.5
Sound level dB(A) 70
Weight (kg) 1600
Humidity (%) 80
Input voltage AC380V 50Hz 3-phase
Protection degree (IPXXX) IP23
System pressure 23MPa
161TA6944
Type TP120
Capacity (kg) 120000
Max tyre dimension 1000x20
Total length (mm) 2080
Total width (mm) 850
Total height (mm) 2151
Operating pressure (bar) 230
Cylinder stroke (mm) 400
Oil tank capacity (L) 30
Electric motor power (kW) 7.5
Sound level dB(A) 70
Weight (kg) 1600
Humidity (%) 80
Input voltage AC220V 50Hz 3-phase
Protection degree (IPXXX) IP23
System pressure 23MPa
