8. Pull the tank clamp toward you and unlock
the tank bands.
9. Raise the tank bands away from you and re-
move the LPG tank.
Installing the LPG Tank
1. Put the LPG tank on the bracket.
(1) The outflow valve must face the right or
upper side of the vehicle.
(2) The tank must be placed with the correct
side up. Find a marking on the tank. It must face
upward or rearward.
2. Put bands over the tank, hook clamps to bands
and push clamps up to clamp the tank.
3. Remove the set pin, turn the tank bracket
around the pivot and set the bracket stopper knob
accurately.
4. Unlock the tank bracket by pulling the set
pin under the tank bracket. Raise the tank bracket
and fix the set pin.
Warning
It is dangerous to unlock the set pin without
the load (tank) because the bracket may jump
up due to the spring force. Unlock the set pin
while the tank is loaded on the bracket.
Remove the set pin, turn the tank bracket
around the pivot and set the bracket stopper
knob accurately.
