TP-Link AC1750 User Manual

Archer C8
AC1750 Wireless Dual Band Gigabit Router
- 94 -
Click the Disable All button to disable all the entries.
Click the Delete All button to delete all the entries.
Click the Previous button to view the information in the previous screen, click the Next button to
view the information in the next screen.
5.14.2 System Routing Table
Choose menu “Advanced
→
Advanced Routing
→
System Routing Table”, and then you can
view the System Routing Table in the next screen (shown in
Figure 5-82). System routing table
views all of the valid route entries in use. The Destination IP address, Subnet Mask, Gateway, and
Interface will be displayed for each entry.
Figure 5-82 System Routing Table
 Destination Network - The Destination Network is the address of the network or host to
which the static route is assigned.
 Subnet Mask - The Subnet Mask determines which portion of an IP address is the network
portion, and which portion is the host portion.
 Gateway - This is the IP address of the gateway device that allows for contact between the
router and the network or host.
 Interface - This interface tells you either the Destination IP Address is on the LAN & WLAN
(internal wired and wireless networks), or on the WAN (Internet).
5.15 Bandwidth Control
Figure 5-83 Bandwidth Control
There are two submenus under the Bandwidth Control menu as shown in Figure 5-83: Control
Settings and Rules List. Click any of them, and you will be able to configure the corresponding
function. The detailed explanations for each submenu are provided below.

TP-Link AC1750 Specifications

General

Interface	WLAN
Connectivity technology	Wireless
Chipset	-
Internal	Yes
Certification	CE, FCC
Modulation	16-QAM, 64-QAM, CCK, DBPSK, DQPSK, OFDM
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	1300 Mbit/s
WLAN data transfer rates supported	11, 54, 450, 1300 Mbit/s
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8.1, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	RoHS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	120.8 mm
Width	115.2 mm
Height	21.5 mm
