TP-Link AC1750 - The Rear Panel

Archer C8
AC1750 Wireless Dual Band Gigabit Router
- 5 -
(WPS)
On/Off
It turns on when a wireless device has been
successfully connected to the network via WPS. After
about 5 minutes, the WPS LED will turn off.
Slow Flash
A wireless device is trying to connect to the network via
WPS. This process may take up to 2 minutes.
Quick
Flash
A wireless device failed to connect to the network via
WPS.

Note:
After a device is successfully added to the network by WPS function, the WPS LED will keep on
for about 5 minutes and then turn off.
1.4.2 The Rear Panel
Figure 1-1 Rear Panel sketch
The following parts are located on the rear panel (View from left to right).
 USB 2.0: The USB 2.0 port connects to a USB 2.0 storage device or a USB 2.0 printer.
 RESET/WPS:
Pressing this button for less than 5 seconds enables the WPS function. If your client devices,
such as wireless adapters, that support Wi-Fi Protected Setup, then you can press this
button to quickly establish a connection between the router and client devices and
automatically configure wireless security for your wireless network.
