TP-Link AC1750 User Manual

Archer C8
AC1750 Wireless Dual Band Gigabit Router
- 95 -

Note:
Bandwidth Control will become invalid if NAT Boost is enabled. If you want to enable Bandwidth
Control, please go to “Advanced
→
NAT Boost” to disable NAT Boost first.
5.15.1 Control Settings
Choose menu “Advanced
→
Bandwidth Control
→
Control Settings”, and then you can
configure the Egress Bandwidth and Ingress Bandwidth in the next screen. For optimal control of
the bandwidth, please select the right Line Type and ask your ISP for the total bandwidth of the
egress and ingress.
Figure 5-84 Bandwidth Control Settings
 Enable Bandwidth Control - Select this checkbox so that the Bandwidth Control settings
can take effect.
 Line Type - Select the right type for you network connection. If you don’t know how to choose,
please ask your ISP for the information.
 Egress Bandwidth - The upload speed through the Internet port
.
 Ingress Bandwidth - The download speed through the Internet port.
5.15.2 Rules List
Choose menu “Advanced
→
Bandwidth Control
→
Rules List”, and then you can view and
configure the Bandwidth Control rules in the screen below.
Figure 5-85 Bandwidth Control Rules List

TP-Link AC1750 Specifications

General

Interface	WLAN
Connectivity technology	Wireless
Chipset	-
Internal	Yes
Certification	CE, FCC
Modulation	16-QAM, 64-QAM, CCK, DBPSK, DQPSK, OFDM
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	1300 Mbit/s
WLAN data transfer rates supported	11, 54, 450, 1300 Mbit/s
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8.1, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	RoHS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	120.8 mm
Width	115.2 mm
Height	21.5 mm
