TP-Link AC1750 User Manual

Archer C8
AC1750 Wireless Dual Band Gigabit Router
- 60 -
 Allow Guests To Access My Local Network - If this checkbox is selected, anyone who
connects to the guest network has access to your local network, not just Internet access.
 Enable Guest Network Bandwidth Control - If this checkbox is selected, the Guest
Network Bandwidth Control rules will take effect.
1) Egress Bandwidth For Guest Network - Specify the upload speed through the
WAN port for Guest Network.
2) Ingress Bandwidth For Guest Network - Specify the download speed through the
WAN port for Guest Network.
 Wireless 2.4GHz
 Enable Guest Network (2.4G) - Select this checkbox to enable 2.4GHz guest network.
 Network Name - Enter a value of up to 32 characters. The same Name (SSID) must be
assigned to all wireless devices in your Guest Network.
 Guest Number - Limit the number of the guest.
 Wireless Security - You can configure the security of Guest Network here.
 Access Time - During this time the wireless stations could access the AP.
 Wireless 5GHz
 Enable Guest Network (5G) - Select this checkbox to enable 5GHz guest network.
 Network Name - Enter a value of up to 32 characters. The same Name (SSID) must be
assigned to all wireless devices in your Guest Network.
 Guest Number - Limit the number of the guest.
 Wireless Security - You can configure the security of Guest Network here.
 Access Time - During this time the wireless stations could accessing the AP.

Note:
The range of bandwidth for Guest Network is calculated according to the setting of Bandwidth
Control on the page “Bandwidth Control->Control Settings”.
5.7 DHCP
Figure 5-39 The DHCP menu

TP-Link AC1750 Specifications

General

Interface	WLAN
Connectivity technology	Wireless
Chipset	-
Internal	Yes
Certification	CE, FCC
Modulation	16-QAM, 64-QAM, CCK, DBPSK, DQPSK, OFDM
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	1300 Mbit/s
WLAN data transfer rates supported	11, 54, 450, 1300 Mbit/s
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8.1, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	RoHS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	120.8 mm
Width	115.2 mm
Height	21.5 mm
