97
Figure 8-3 Working Process
CAP
Master AC: 192.168.1.253
Standby AC:192.168.1.252
CAP
Core Switch
PoE Switch
PoE Switch
Master AC: 192.168.1.252
Standby AC:192.168.1.253
Note:
Standby AC should be congured along with the link priority. The AC with higher priority becomes the master
AC and the lower one is the standby AC.
