TP-Link AC50 User Manual

56
Advertisement Specify whether to enable the Advertisement feature. With this feature enabled,
you can add advertisement pictures on the authentication page. These
advertisement pictures will be displayed before the login page appears. The
required parameters are as follows:
Picture Resouce: You can add up to 5 advertisement pictures. When several
pictures are added, they will be played in a loop. There are two picture
resources: Local Upload and External Link.
Advertisement Duration Time: Specify how long the advertisement will be
displayed for. For this duration, the pictures will be played in a loop. Enter
a value from 1 to 30 seconds. If the duration time is not enough for all the
pictures, the rest will not be displayed.
Photo Carousel Interval: Specify the picture carousel interval. If this value
is set as 5 seconds, the first picture will be displayed for 5 seconds, followed
by the second picture for 5 seconds, and so on. Enter a value from 1 to 10
seconds.
Allow to Skip Advertisement: Specify whether to enable this feature. With this
feature enabled, the user can click the Skip button to skip the advertisement.
Description Specify a description for the Voucher entry to make it easier to search for and
manage.
7.2.5 SMS
In SMS Authentication, the client can get a verification code using a mobile phone and
enter the code to pass the authentication.
Choose the menu Authentication > Portal Authentication > SMS to load the following
page.
Figure 7-16 SMS Page
Here you can view the SMS Authentication information and edit the entries.
Click
to add a new entry.

TP-Link AC50 Specifications

General

Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	5
Input voltage	100 - 240 V
Input frequency	50/60 Hz
VLAN support	Yes
Security algorithms	802.1x RADIUS, SSID, WPA, WPA-PSK, WPA2, WPA2-PSK
Authentication method	MAC
Certification	CE, FCC, RoHS
Product color	Black
Cables included	AC
Compatible operating systems	Windows 10, Windows 8, Windows 7, Windows Vista, Windows XP, MAC OS, NetWare, UNIX, Linux
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Flash memory	16 MB
Internal memory	128 MB
Processor frequency	650 MHz
Control display unit	-
Internal memory type	DDR2
Number of processors installed	1
Package type	Box
Package depth	223 mm
Package width	285 mm
Package height	68 mm
Package weight	1030 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	126 mm
Width	209 mm
Height	26 mm
