73
Click to add a new entry. There are two Match Modes, including Five Tuple Type and
URL Type.

Five Tuple Type
Five Tuple Type is configured based on the IP address range, MAC address, VLAN ID,
port and protocol. It is recommended to select Five Tuple Type when there are many
parameters to be configured in the free authentication policy.
Figure 7-34 Five Tuple Type
Strategy Name Specify a name for the free authentication policy entry.
Match Mode Specify a match mode for the free authentication policy.
Source IP Range Specify the source IP address and subnet mask of the free authentication
policy entry.
Source MAC Address Specify the source MAC address of the free authentication policy entry.
Source VLAN Specify the source VLAN ID of the free authentication policy entry.
Source Port Specify the source port range of the free authentication policy entry.
Destination IP Range Specify the destination IP address and subnet mask of the free authentication
policy entry.
Destination Port Specify the destination source MAC address of the free authentication policy
entry.
Protocol Specify the service protocol of the free authentication policy entry.
