TD-W8970
3
00Mbps Wireless N Gigabit ADSL2+ Modem Router User Guide
82
Figure 4-81
2. Create a unique description for the schedule (e.g. Schedule_1) in Description field.
3. Select the day or days you need in Apply To field.
4. In time field, you can select all day-24 hours or you may enter the Start Time and Stop Time
in the corresponding field.
5. Click Save to save the settings.
Click the Clear Schedule button to clear your settings in the table.
Click the Delete Selected button to delete selected entries.
4.14 IPv6 Tunnel
IPv6 tunnel is a kind of transition mechanism to enable IPv6-only hosts to reach IPv4 services and
to allow isolated IPv6 hosts and networks to reach each-other over IPv4-only infrastructure before
IPv6 completely supplants IPv4. It is a temporary solution for networks that do not support native
dual-stack, where both IPv6 and IPv4 run independently.
Choose menu “IPv6 Tunnel”, and you will see the screen as shown in Figure 4-82.
Figure 4-82
¾ Enable: Check the box to enable IPv6 Tunnel function. It is disabled by default.

Table of Contents

Other manuals for TP-Link td-w8970

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TP-Link td-w8970 and is the answer not in the manual?

TP-Link td-w8970 Specifications

General IconGeneral
VPN supportPPTP, L2TP, IPSec Pass-through
Ethernet LANYes
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity10
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Antennas quantity2
Antenna connector typeRP-SMA
Antenna gain level (max)5 dBi
DHCP client-
Routing protocolsRIP-1, RIP-2
Supported network protocolsDHCP, ATM/PPP
RJ-11 ports quantity1
Ethernet LAN (RJ-45) ports4
Security algorithms128-bit AES, 128-bit WEP, 256-bit AES, 3DES, 64-bit WEP, DES, MD5, SHA-1, SSL/TLS, WPA, WPA-PSK, WPA2, WPA2-PSK, WPS
Authentication methodMD5, SHA-1
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 90 %
CertificationCE, FCC, RoHS, IPv6
Cables includedLAN (RJ-45)
USB version2.0
CompatibilityIPv6
Input current1.5 A
Input voltage12 V
Rack mountingNo
Frequency band2.4 GHz
Frequency range2.4 - 2.4835 GHz
Filtering descriptionMAC / IP / URL
WLAN data transfer rates supported300 Mbit/s
Product colorBlack
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 4 (802.11n)
Power source typeDC
Weight and Dimensions IconWeight and Dimensions
Depth140 mm
Width225 mm
Height32.5 mm
Weight- g
