TP-Link TD-W9970 User Manual

TD-W9970
300Mbps Wireless N USB VDSL2 Modem Router User Guide
Chapter 1. Product Overview
Thank you for choosing the TD-W9970 300Mbps Wireless N USB VDSL2 Modem Router.
1.1 Overview of the Modem Router
The TD-W9970 300Mbps Wireless N USB VDSL2 Modem Router integrates 4-port Switch,
Firewall, NAT-Router and Wireless AP. The Modem Router delivers exceptional range and speed,
which can fully meet the need of Small Office/Home Office (SOHO) networks and the users
demanding higher networking performance.
The TD-W9970 300Mbps Wireless N USB VDSL2 Modem Router utilizes integrated VDSL2
transceiver and high speed MIPS CPU. The modem router supports full-rate VDSL2 connectivity
conforming to the ITU and ANSI specifications.
In addition to the basic DMT physical layer functions, the VDSL2 PHY supports dual latency
VDSL2 framing (fast and interleaved) and the I.432 ATM Physical Layer.
The modem router provides up to 300Mbps (2.4GHz) wireless connection with other 802.11n wireless
clients. The incredible speed makes it ideal for handling multiple data streams at the same time, which
ensures your network stable and smooth. The performance of this 802.11n wireless Router will give
you the unexpected networking experience at speed much faster than 802.11g. It is also compatible
with all IEEE 802.11g and IEEE 802.11b products.
With multiple protection measures, including SSID broadcast control and wireless LAN 64/128
WEP encryption, Wi-Fi protected Access (WPA2-PSK, WPA-PSK), as well as advanced Firewall
protections, the TD-W9970 300Mbps Wireless N USB VDSL2 Modem Router provides complete
data privacy.
The modem router provides flexible access control, so that parents or network administrators can
establish restricted access policies for children or staff. It also supports Virtual Server and DMZ
host for Port Triggering, and then the network administrators can manage and monitor the network
in real time with the remote management function.
Since the modem router is compatible with virtually all the major operating systems, it is very easy
to manage. Quick Setup Wizard is supported and detailed instructions are provided step by step in
this user guide. Before installing the modem router, please look through this guide to know all the
modem router’s functions.
2

TP-Link TD-W9970 Specifications

General

VPN support	PPTP, L2TP, IPSec Pass-through
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Number of guest networks (2.4 GHz)	1
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
USB version	2.0
Rack mounting	-
Frequency range	2.4 - 2.4835 GHz
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
DMZ support	No
Security algorithms	128-bit AES, 128-bit WEP, 192-bit AES, 256-bit AES, 3DES, 64-bit WEP, DES, MD5, SHA-1, WPA, WPA-PSK, WPA2, WPA2-PSK
Antennas quantity	2
Antenna gain level (max)	5 dBi
Product type	Tabletop router
Product color	White
Certification	CE, FCC, RoHS
Mac operating systems supported	macOS
Windows operating systems supported	Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows XP
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45), Phone (RJ-11)
WAN connection type	RJ-45
Output current	1 A
Output voltage	12 V
Power source type	DC
Package depth	232 mm
Package width	260 mm
Package height	70 mm
Package weight	550 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	130 mm
Width	195 mm
Height	36 mm
Weight	- g
