Configuration Guide 34
Configuring Network VLAN Configuration
Viewing the VLANs
Choose the menu Network > VLAN > VLAN to load the following page.
Figure 7-2 Viewing the VLAN
In the VLAN list you can view all the VLANs existing in the router.
VLAN ID Displays the VLAN ID.
Name Displays the VLAN name.
Ports Displays the ports which belongs to the corresponding VLAN.
Description Displays the description of the VLAN.
Note:
The VLAN list contains all the VLANs existing in the router. Some of them are manually created by
the user, and can be edited or deleted. Some are automatically created and referenced by the router
for some special scenarios like IPTV or management VLAN, and you cannot edit or delete these
VLANs.
7.2 Configuring the PVID of a Port
Choose the menu Network > VLAN > Port to load the following page.
