Chapter Introduction
Chapter 5 Monitoring This module is used to monitor the traffic information of the
switch, and
provide the convenient method to locate and
solve the network problem.
Port Statistics: View the statistic information of each port.
Port Mirr
or: Monitor and mirror network traffic by
forwarding copies of incoming and outgoing packets
from one/multiple ports (mirrored port) to a specific port
(mirroring port).
Cable Test: Diagnose the connection status of the cable
connected to the switch and the distance to the problem
location.
Loop Prevention: Detect loops using loopback detection
packets, and then display an alert or further block the
corresponding port.
Chapter 6 VLAN
This module is used to configure VLANs to control
broadcast in LANs. Here mainly introduces:
MTU VLAN: Set the MTU VLAN mode.
Port Based VLAN: Set the Port-Based VLAN mode
802.1Q VLAN: Set the 802.1Q Tag VLAN mode.
802.1Q PVID Setting: Configure 802.1Q PVID value.
Chapter 7 QoS This module is used to configure QoS function to provide
different quality of service for various network applications
and requirements. Here mainly introduces:
QoS Basic: Configure and view the basic parameters of
QoS.
Bandwidth Control: Configure and view the bandwidth
control function information.
Sto
rm Control: Configure and view the storm control
function information.
Chapter 8 PoE
This module is used to configure the PoE function for the
switch to supply power for PD devices.
Chapter 9 Help Lists the help and version information of the utility.
