Chapter 16 VPN Server&Client
To use the VPN feature, you need to set up IPSec VPN Server on your router, and
configure theIPSec connection on remote devices. Please follow the steps below to
set up the IPSec VPN connection.
Home Network Router (VPN Server) Remote Devices
Step 1. Set up IPSec VPN Server on Your Router
1. Visit http://tplinkmodem.net or http://192.168.1.1, and log in with the password you
set for the GPON router.
2. Go to Advanced > VPN > IPSec VPN, and enable Dead Peer Detection.
Note:
• Firmware update may be required to support IPSec VPN Server.
• Before you enable Dead Peer Detection, we recommend you configure Dynamic DNS Service (recommended) or
assign a static IP address for router’s WAN port and synchronize your System Time with internet.
3. Click Add.
4. Configure the IPSec VPN server parameters.
To Next Page
