OPERATOR CONTROL CIRCUIT BOARD
SERVICE MANUAL
TIREBOSS
TM
Tire Pressure Control
BACK OF
CAB CONTROLLER
J1
J2
J5
J6
J8
ELTEK 1483-00
SPEED BOARD
OPERATOR CONTROL
CIRCUIT BOARD
654321
Speed Board Mount
Stand Off Posts
Sonalert
Header
Programming
Header
Datalogger
Header
Power/Data
Header
Power ON/
OFF Header
J4
Speed Board
Header
Speed/Ignition
Header
SPEED BOARD POSITION LABEL (J or P)
