TPC TIREBOSS - Page 41

SERVICE MANUAL
TIREBOSS
TM
Tire Pressure Control
3-16
f:tec\manuals\Service\SERVICEv5.indd - V6-0615
*SIDE VIEW
*view from top of VCM
Air line to Transducer
Connection to CPU
circuit board
Attach Red probe here
for input reading
Attach Red probe here
for output reading
Transducer
Adjusting Screw
Transducer Manifold
Transducer
Transducer Wires (Red Green and Black)
Transducer Adjusting Screw
Transducer Manifold
“TRANS RANGE ERROR” ALERT ... con’t
Ground Terminal
(-VBAT)
Positive Terminal
(+VBAT)
