Assembly Instructions | ILM Servo Kits
16 Edition 03/2021 EN
ILM servo kit configurations
4 ILM SERVO KIT CONFIGURATIONS
4.1 Basic servo kit with connection board
Possible configurations:
— Star-serial
— Star-parallel
— Delta-serial
— Delta-parallel
A temperature sensor is included as standard.
4.2 Servo kit with Hall commutation
Basic servo kit with:
— Digital Hall elements
— Extended rotor
4.3 Servo kit with three pins on the stator
The servo kit without connection board is available
with three pins on the stator as a custom solution.
Possible configurations:
— Star-serial
Fig. 6: Basic servo kit with
connection board
Fig. 7: Servo kit with Hall
commutation
Fig. 8: Servo kit with three pins on
the stator
