9.1.1 Attribute 1, Number of Attributes
Number of Attributes returns the number of supported Position Sensor Object attributes.
Link path, Packed EPATH with 8-bit class
0x20
0x23
0x24
0x01
0x30
0x01
Logical Type =
Class
Class #23
Logical Type =
Instance
Instance #1
Logical Type =
Attribute ID
Attribute ID #1
9.1.2 Position Value Unsigned
The current, non-safety-related, scaled absolute actual position of the measuring system is output as
an unsigned 32-bit binary value via the Attribute Position Value Unsigned.
UDINT, read only
Byte
0 1 2 3
Bit
7-0 15-8 23-16 31-24
Data
2
7
– 2
0
2
15
– 2
8
2
23
– 2
16
2
31
– 2
24
9.1.3 Attribute 11, Position Sensor Type
Position Sensor Type returns the device type:
UINT, read only
Value Definition
02
Absolute multi-turn encoder
Link path, Packed EPATH with 8-bit class
0x20
0x23
0x24
0x01
0x30
0x0B
Logical Type =
Class
Class #23
Logical Type =
Instance
Instance #1
Logical Type =
Attribute ID
Attribute ID #11
9.1.4 Attribute12, Direction Counting Toggle
Danger of death, severe personal injury and/or material damage due to a
jump in the absolute value when changing the counting direction function!

The internal calculation algorithm results in different absolute positions
for the counting direction settings ascending and descending
. Verify
the correct function by a test run in safe mode after changing th
e
counting direction. Under certain circumstances, the output position
must be adjusted via the preset function.
