11 Obtain IP parameters via Flash or DHCP
The TCP/IP Interface Object is used to configure the TCP/IP network interface; it contains,
among other things, device IP address, network mask, and gateway address. The settings are made
via the Object 0xF5, Instance 1, and the Attributes 3 Configuration Control and 5
Interface Configuration. The attributes are generally controlled via a DHCP server program,
see 80.
11.1 Object 0xF5, Instance 1
Attr. ID Access Name Data type Description Default Page
3 Set/Get
Configuration
Control
DWORD
Interfaces
Control flags set
the configuration
options.
The device
obtains the IP
parameters via
DHCP if the
hardware switch =
77
5 Set/Get
Interface
Configuration
STRUCT
of:
TCP/IP network
78
IP Address UDINT
configures the
device IP address
FLASH content 78
Network Mask UDINT
configures the
device subnet mask
FLASH content 78
Gateway
Address
UDINT
configures the
device gateway
FLASH content 78
Domain Name STRING
configures the
domain name
0 78
6 Set/Get Host Name STRING
0 –
Table 8: TCP/IP interface object 0xF5, Instance 1, Attributes 3 and 5
11.1.1 Attribute 3, Configuration Control
The Configuration Control attribute is bit-coded and defines how the IP parameters are
assigned to the measuring system during the start-up phase, see also “Obtaining IP Parameters” on
Page78.
Bit Function Description
0-3
Startup
Configuration
Value = 0: A FLASH provides the IP parameters to the measuring system.
Value = 2: A DHCP provides the IP parameters to the measuring system.
Attribute 3 is not evaluated if the switch positions are different; hardware
switch specifications apply.
0 (FALSE): is not supported
