TR-Electronic CDV582 - Preset Value; TR Grey - Preset Control

Parameter description
 TR-Electronic GmbH 2020, All Rights Reserved Printed in the Federal Republic of Germany
Page 56 of 91 TR-ECE-BA-GB-0163 v03 10/07/2020
BYTE, BOOL
Value Description Default
0
Measuring system – position ascending clockwise
(looking at shaft, flange connection)
X
1
Measuring system – position descending clockwise
(looking at shaft, flange connection)
Link path, Packed EPATH with 8-bit class
0x20
0x23
0x24
0x01
0x30
0x0C
Logical Type =
Class
Class #23
Logical Type =
Instance
Instance #1
Logical Type =
Attribute ID
Attribute ID #12
9.1.5 Preset Value
The Attribute Preset Value contains the adjustment value, which is set as the new position value if
the adjustment function is triggered via the Attribute TR Grey – Preset Control. The attribute is
integrated into the cyclic data traffic via the IO Assembly Instance 102,
Grey Output Channel 1 (adjustment function),
see Chapter 7.3 on Page 45.
DINT, Default: 0
Byte
0 1 2 3
Bit
7-0
15-8
23-16
31-24
Data
2
7
– 2
0
2
15
– 2
8
2
23
– 2
16
2
31
– 2
24
9.1.6 TR Grey – Preset Control
The Attribute TR Grey – Preset Control (control word) contains the control bit for the
adjustment function and is integrated into the cyclic data traffic via the IO Assembly Instance 102,
Grey Output Channel 1 (adjustment function),
see Chapter 7.3 on Page 45.
WORD
Byte
0 1
Bit
7-0 15-8
Data
2
7
– 2
0
2
15
– 2
8
