9.1.9 TR Grey – Rotational Direction
Danger of death, severe personal injury and/or material damage due to a
jump in the absolute value when changing the counting direction function!

The internal calculation algorithm results in different absolute positions
for the counting direction settings ascending and descending
. Verify
the correct function by a test run in safe mode after changing the
counting direction. Under certain circumstanc
es, the output position
must be adjusted via the preset function.
BYTE, BOOL
Value Description Default
0
Measuring system – position descending clockwise
(looking at shaft, flange connection)
1
Measuring system – position ascending clockwise
(looking at shaft, flange connection)
X
