13 Elementary data types
Data type Code Description
BOOL 0xC1 Boolean variable with the values TRUE and FALSE
SINT 0xC2 Signed 8 Bit Integer
INT 0xC3 Signed 16 Bit Integer
DINT 0xC4 Signed 32 Bit Integer
LINT 0xC5 Signed 64 Bit Integer
USINT 0xC6 Unsigned 8 Bit Integer
UINT 0xC7 Unsigned 16 Bit Integer
UDINT 0xC8 Unsigned 32 Bit Integer
ULINT 0xC9 Unsigned 64 Bit Integer
REAL 0xCA 32 Bit Floating Point
LREAL 0xCB 64 Bit Floating Point
STRING 0xD0 Character string, 1 byte / character
BYTE 0xD1 Bit string, 8 bit
WORD 0xD2 Bit string, 16 bit
DWORD 0xD3 Bit string, 32 bit
LWORD 0xD4 Bit string, 64 bit
SHORT_STRING 0xDA Character string, 1 byte / character, 1 byte length index
EPATH 0xDC CIP path segment
STRINGI 0xDE International Character String
