Trane Ascend ACR C Series User Manual

18
AC-SVX003A-EN
Dimensions and Weights
Weights
Table 4. Weights — 150 to 330 ton units
Unit
Size
(tons)
Condenser
Length
(a)
Free
Cooling
Option
(b)
Pump Option
(c)
Standard Length Extended Length
(d)
Shipping Operating Shipping Operating
lb
kg
lb
kg
lb
kg
lb
kg
150 4V N/A N/A 12000 5450 12200 5540 14200 6450 14400 6540
165
4V N/A N/A 12100 5490 12200 5540 14200 6450 14400 6540
5V N/A N/A 13100 5950 13200 5990 15200 6900 15400 6990
5V TDFC N/A 16000 7260 17200 7810 18800 8530 20100 9120
5V DFC1 N/A 17300 7830 19100 8670 20000 9040 21800 9880
5V DFC2 N/A 18100 8190 20000 9030 20800 9400 22600 10240
180
4V N/A N/A 12200 5540 12400 5630 14600 6630 14800 6720
5V N/A N/A 13400 6080 13500 6130 15500 7040 15700 7130
5V TDFC N/A 16800 7630 18000 8170 19700 8940 19900 9030
5V DFC1 N/A 17800 8040 19600 8890 20200 9160 22100 10000
5V DFC2 N/A 19200 8680 21000 9530 21000 9530 22900 10380
200
5V N/A N/A 13400 6080 13600 6170 15600 7080 15700 7130
6V N/A N/A 14600 6630 14800 6720 16600 7530 16800 7630
6V TDFC N/A 18600 8440 20000 9080 20900 9490 22400 10170
6V DFC1 N/A 20400 9220 22400 10160 22900 10370 25000 11310
6V DFC2 N/A 21500 9740 23600 10690 22400 10140 26200 11870
225
5V N/A N/A 14800 6720 15000 6810 17000 7720 17200 7810
6V N/A N/A 15900 7220 16100 7310 18100 8220 18300 8310
6V TDFC N/A 19900 9030 21300 9670 22300 10120 23800 10800
6V DFC1 N/A 20700 9360 22800 10310 23200 10510 25300 11460
6V DFC2 N/A 21800 9850 23900 10800 24500 11070 26600 12050
250
5V N/A N/A 14900 6760 15100 6850 17000 7720 17200 7810
6V N/A N/A 16300 7400 16500 7490 18400 8350 18700 8490
6V TDFC N/A 20300 9210 21700 9850 22700 10300 24200 10980
6V DFC1 N/A 20700 9380 22800 10340 23300 10530 25400 11490
6V DFC2 N/A 21800 9870 23900 10830 24500 11090 26700 12080
275
6V N/A N/A 16300 7400 16600 7530 18500 8400 18800 8530
6V TDFC N/A 19900 9000 21800 9860 22600 10210 24500 11080
7V N/A N/A 17400 7900 17700 8030 19600 8900 19800 8990
7V TDFC N/A 23900 10900 24200 10950 26400 12000 26600 12050
7V DFC1 N/A 22800 10330 24900 11290 25300 11450 27500 12440
7V DFC1 PUMP 27000 12220 30700 13910 29400 13340 33200 15060
7V DFC2 N/A 23900 10830 26200 11870 26100 11830 28400 12880
7V DFC2 PUMP 28100 12720 32000 14490 30300 13720 34200 15500
