Trane Ascend ACR C Series User Manual

AC-SVX003A-EN
19
Table 4. Weights — 150 to 330 ton units (continued)
Unit
Size
(tons)
Condenser
Length
(a)
Free
Cooling
Option
(b)
Pump Option
(c)
Standard Length Extended Length
(d)
Shipping Operating Shipping Operating
lb
kg
lb
kg
lb
kg
lb
kg
300
7V N/A N/A 17500 7940 17700 8030 19600 8900 19900 9030
7V TDFC N/A 21800 9890 23900 10840 24400 11040 26500 11990
8V N/A N/A 18500 8400 18800 8530 20700 9390 20900 9490
8V TDFC N/A 23400 10590 25300 11460 25800 11670 27700 12560
8V TDFC PUMP 27600 12470 31100 14080 26900 12160 33500 15180
8V DFC1 N/A 24700 11180 27000 12210 26900 12180 29300 13260
8V DFC1 PUMP 28800 13070 32800 14850 31100 14070 35100 15890
8V DFC2 N/A 25600 11600 27500 12470 27800 12540 30000 13570
8V DFC2 PUMP 29800 13490 33300 15090 31900 14420 35700 16190
330
8V N/A N/A 19100 8650 19500 8830 21400 9680 21800 9870
8V TDFC NONE 23800 10780 26000 11780 26300 11920 28600 12940
8V TDFC PUMP 28000 12670 31800 14410 30500 13800 34400 15570
9V N/A NONE 20300 9200 20800 9400 22300 10100 22700 10280
9V TDFC NONE 25500 11570 27900 12630 27700 12570 30100 13650
9V TDFC PUMP 29700 13450 33700 15270 31900 14450 35900 16270
9V DFC1 N/A 26200 11870 28700 12980 27900 12640 30300 13730
9V DFC1 PUMP 30400 13760 34400 15610 32100 14530 36100 16350
Notes:
1. Weights include factory charge of refrigerant and oil, ultimate sounds, and architectural louvered panels.
2. All weights are plus/minus 10%
(a)
Condenser length defined by model number digit 25: 4V = A; 5V = B; 6V = C; 7V = D; 8V = E; 9V = F
(b)
Direct Free Cooling defined by model number digit 42: T=TDFC; J=DFC1; H=DFC2.
(c)
Pump Package defined by model number digit 40 = 5, 6, 7
(d)
Extended Length is required for voltages 200V, 230V, 380V, 400V, 575V (model number digit 9 = A, B, C, D, F), and harmonic filtration model number digit 44 = L.
Table 5. Weights — 375 to 550 ton units
Unit Size
(tons)
Condenser
Length
(a)
Standard Unit with SPP
(b)
Std Unit with SPP and Options Box
(c)
Shipping Operating Shipping Operating
lb
kg
lb
kg
lb
kg
lb
kg
Units without Direct Free-Cooling
(d)
375 9V 22900 10390 23300 10570 25500 11570 25900 11750
440 9V 22900 10390 23300 10570 25500 11570 25900 11750
380 11V 25200 11440 25500 11570 27200 12340 27600 12520
450 11V 25200 11440 25500 11570 27200 12340 27600 12520
500 11V 27400 12430 27900 12660 29500 13390 29900 13570
550 11V 27400 12430 27900 12660 29500 13390 29900 13570
Units with Direct Free-Cooling
(d)
380 11V 30900 14020 32400 14700 33400 15150 34900 15840
450 11V 30900 14020 32400 14700 33400 15150 34900 15840
500 11V 33100 15020 34800 15790 35200 15600 36800 16700
550 11V 33100 15020 34800 15790 35200 15600 36800 16700
Notes:
1. Weights include factory charge of refrigerant and oil, architectural louvered panels, and Superior sound option.
2. All weights are plus/minus 10%.
(a)
Condenser length defined by model number digit 25: 9V = F; 11V = H.
(b)
Single Point Power (SPP) is indicated by model number digit 29 = 1.
(c)
Options box is used for units with either 575V (model number digit 9 = F) or Low Harmonics Option (model number digit 44 = L).
(d)
Direct Free-Cooling defined by model number digit 42 = T.
Dimensions and Weights
