Trane Ascend ACR C Series User Manual

AC-SVX003A-EN
33
Table 15. Dimensions — 375 to 550 ton units
Unit Size
(tons)
375, 440 375, 440 380, 450 500, 550
Unit Length
Standard
Extended
(a)
Standard Standard
Dimension in mm in mm in mm in mm
A 52.4 1330 52.4 1330 56.1 1424 56.1 1424
B 99.6 2530 152.0 3860 174.2 4424 174.2 4424
C 180.6 4588 233.0 5918 252.9 6424 252.9 6424
D 298.7 7588 351.1 8918 371.0 9424 371.0 9424
E 377.5 9588 429.8 10918 457.6 11624 457.6 11624
F 474.4 12050 547.9 13917 528.5 13424 528.5 13424
G 77.2 1962 77.2 1962 60.7 1542 60.7 1542
H 196.5 4990 196.5 4990 218.2 5542 218.2 5542
I 332.9 8455 332.9 8455 354.6 9007 354.6 9007
J 463.4 11770 490.4 12455 526.7 13377 526.7 13377
K 504.3 12810 551.7 14012 604.5 15355 604.5 15355
L
(b)
517.5 13146 570.4 14487 623.2 15829 623.2 15829
M 200.7 5098 200.7 5098 253.5 6440 253.5 6440
N 333.9 8480 333.9 8480 386.7 9822 389.8 9902
O 200.7 5098 200.7 5098 253.5 6440 253.5 6440
P 200.7 5098 200.7 5098 253.5 6440 253.5 6440
(a)
Extended Length Units are defined model number digit 44 = L and model number digit 9: 380 = C, 400=D, 575 = F or model number digit 9: 380 = C,400 = D ,575 = F.
(b)
Total unit length includes additional extruded features such as circuit breaker handles.
Dimensions and Weights
