AC-SVX003A-EN
39
Point Weights
Table 18. Point weights - I-P (lb)
Cond
(a)
Free-
Cooling
(b)
Pump
(c)
Unit
Size
Mounting Location
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Standard Length Units
4V N/A N/A 150 1820 1610 1870 1680 1720 1790 740 940 n/a n/a n/a n/a n/a n/a n/a n/a
4V N/A N/A 165 1820 1620 1870 1690 1730 1800 740 940 n/a n/a n/a n/a n/a n/a n/a n/a
4V N/A N/A 180 1830 1630 1890 1710 1750 1830 750 960 n/a n/a n/a n/a n/a n/a n/a n/a
5V NONE N/A 165 1760 1710 1910 1860 1950 1970 950 1100 n/a n/a n/a n/a n/a n/a n/a n/a
5V NONE N/A 180 1780 1760 1940 1930 1980 2050 960 1130 n/a n/a n/a n/a n/a n/a n/a n/a
5V NONE N/A 200 1780 1770 1950 1930 1990 2060 960 1130 n/a n/a n/a n/a n/a n/a n/a n/a
5V NONE N/A 225 1960 1880 2170 2150 2210 2330 1020 1270 n/a n/a n/a n/a n/a n/a n/a n/a
5V NONE N/A 250 1970 1890 2180 2160 2220 2340 1020 1270 n/a n/a n/a n/a n/a n/a n/a n/a
5V TDFC N/A 165 1910 1960 2010 2070 2620 2880 1200 1530 n/a n/a n/a n/a n/a n/a n/a n/a
5V TDFC N/A 180 1750 1860 2480 2600 2560 2810 1290 1610 n/a n/a n/a n/a n/a n/a n/a n/a
5V DFC1 N/A 165 1910 1990 2360 2520 2480 2800 1750 2400 350 590 n/a n/a n/a n/a n/a n/a
5V DFC1 N/A 180 1830 2030 2500 2600 3010 2880 1060 2430 710 590 n/a n/a n/a n/a n/a n/a
5V DFC2 N/A 165 1720 1710 1970 2090 2180 2420 2340 2930 1030 1560 n/a n/a n/a n/a n/a n/a
5V DFC2 N/A 180 1780 1790 2090 2210 2340 2570 2510 3090 1070 1600 n/a n/a n/a n/a n/a n/a
6V NONE N/A 200 1800 1850 1990 1910 1970 1950 1290 1400 280 300 n/a n/a n/a n/a n/a n/a
6V NONE N/A 225 2000 1930 2240 2140 2120 2130 1370 1550 280 330 n/a n/a n/a n/a n/a n/a
6V NONE N/A 250 2050 1980 2300 2200 2180 2190 1390 1560 280 330 n/a n/a n/a n/a n/a n/a
6V NONE N/A 275 2060 2000 2320 2220 2200 2200 1400 1570 280 330 n/a n/a n/a n/a n/a n/a
6V TDFC N/A 200 1900 2030 2130 2210 3070 3340 1090 1310 780 930 n/a n/a n/a n/a n/a n/a
6V TDFC N/A 225 1840 1980 2850 2870 3090 3000 1080 1960 840 720 n/a n/a n/a n/a n/a n/a
6V TDFC N/A 250 1880 2030 2930 2950 3160 3060 1090 1970 830 710 n/a n/a n/a n/a n/a n/a
6V TDFC N/A 275 1840 1950 2930 3010 3280 3330 1190 2390 930 940 n/a n/a n/a n/a n/a n/a
6V DFC1 N/A 200 1680 1630 2370 2430 2460 2750 2550 3340 1340 1890 n/a n/a n/a n/a n/a n/a
6V DFC1 N/A 225 1700 1650 2420 2470 2520 2800 2600 3380 1340 1890 n/a n/a n/a n/a n/a n/a
6V DFC1 N/A 250 1710 1650 2430 2480 2530 2810 2610 3390 1340 1890 n/a n/a n/a n/a n/a n/a
6V DFC2 N/A 200 1680 1710 2420 2370 2560 2570 1990 2740 1790 2340 660 760 n/a n/a n/a n/a
6V DFC2 N/A 225 1690 1730 2460 2410 2610 2610 2020 2770 1800 2350 650 760 n/a n/a n/a n/a
6V DFC2 N/A 250 1700 1740 2470 2420 2620 2620 2030 2780 1800 2350 650 760 n/a n/a n/a n/a
7V NONE N/A 275 1950 1850 2120 1990 2040 2010 1840 2030 870 960 n/a n/a n/a n/a n/a n/a
7V NONE N/A 300 1950 1850 2130 2000 2050 2020 1840 2030 880 960 n/a n/a n/a n/a n/a n/a
Installation Mechanical
