40
AC-SVX003A-EN
Table 18. Point weights - I-P (lb) (continued)
Cond
(a)
Free-
Cooling
(b)
Pump
(c)
Unit
Size
Mounting Location
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
7V TDFC N/A 275 1910 2000 2640 2700 2510 2750 2320 2980 1740 2570 n/a n/a n/a n/a n/a n/a
7V TDFC N/A 300 1790 1740 2480 2530 2550 2830 2650 3420 1690 2250 n/a n/a n/a n/a n/a n/a
7V DFC1 N/A 275 1940 1760 2240 2420 2380 2640 2390 2870 1680 1950 1150 1510 n/a n/a n/a n/a
7V DFC1 PUMP 275 2010 2000 2060 1980 2510 2600 1290 1880 1690 1840 2550 2700 2480 3160 n/a n/a
7V DFC2 N/A 275 1580 1640 2490 2510 2890 2850 2530 3470 2180 2890 560 650 n/a n/a n/a n/a
7V DFC2 PUMP 275 1560 1630 2760 2720 2700 2760 1950 2880 2350 2720 2430 2820 1250 1500 n/a n/a
8V NONE N/A 300 1990 1940 2340 2240 2350 2310 1950 2060 750 870 n/a n/a n/a n/a n/a n/a
8V NONE None 300 1990 1940 2340 2240 2350 2310 1950 2060 750 870 n/a n/a n/a n/a n/a n/a
8V TDFC None 300 1760 1810 2380 2390 2320 2490 2300 2590 1720 1760 1470 2280 n/a n/a n/a n/a
8V TDFC PUMP 300 1910 1960 1970 1960 2450 2600 1290 1900 1720 1890 2640 2830 2570 3340 n/a n/a
8V DFC1 None 300 1720 1700 2510 2570 2650 2890 2740 3440 2250 2900 720 890 n/a n/a n/a n/a
8V DFC1 PUMP 300 1760 1800 2320 2260 2910 2990 2020 2980 2400 2770 2490 2870 1480 1740 n/a n/a
8V DFC2 NONE 300 1940 1760 2030 2450 2670 2710 1990 2240 1910 2160 1750 2150 740 1010 n/a n/a
8V DFC2 PUMP 300 1920 1780 1930 2350 2310 2430 1590 1880 1620 1930 2650 2940 2830 3280 780 1040
8V None None 330 2030 1920 2330 2220 2470 2440 2160 2290 760 890 n/a n/a n/a n/a n/a n/a
8V TDFC None 330 1840 1870 2530 2510 2450 2620 2380 2700 1700 1760 1430 2240 n/a n/a n/a n/a
8V TDFC
Pump
330 1990 1960 2100 2030 2640 2710 1370 1970 1790 1930 2670 2810 2570 3270 n/a n/a
9V None None 330 2050 1990 2970 2890 3050 3130 1730 1840 560 560 n/a n/a n/a n/a n/a n/a
9V TDFC None 330 1810 1810 2570 2620 2650 2900 2690 3390 2230 2870 1090 1270 n/a n/a n/a n/a
9V TDFC
Pump
330 2170 2150 1980 1990 2910 2940 2260 3320 1670 1920 3010 3450 1850 2110 n/a n/a
9V DFC1 None 330 2290 2320 2000 1970 2590 2650 1680 2390 1000 1090 1560 1790 2250 3110 n/a n/a
9V DFC1
Pump
330 2070 1900 2120 2540 2530 2630 1720 2010 1720 2040 2670 2990 2700 3240 630 950
9V NONE N/A 375 1470 1690 1660 1820 2260 2290 2390 2170 2210 1870 1800 1630 n/a n/a n/a n/a
9V NONE N/A 440 1470 1690 1660 1820 2260 2290 2390 2170 2210 1870 1800 1630 n/a n/a n/a n/a
11V NONE N/A 380 2080 2330 1770 1940 2170 2200 2270 2040 2240 1900 2330 2230 n/a n/a n/a n/a
11V NONE N/A 450 2070 2340 1760 1940 2170 2200 2270 2050 2240 1900 2330 2230 n/a n/a n/a n/a
11V NONE N/A 500 2110 2330 1830 1980 2280 2380 2490 2560 2470 2550 2440 2480 n/a n/a n/a n/a
11V NONE N/A 550 2110 2330 1830 1980 2280 2380 2490 2560 2470 2550 2440 2480 n/a n/a n/a n/a
11V TDFC N/A 380 2440 3100 1980 2420 2610 2940 2860 3000 2710 2680 2680 2980 n/a n/a n/a n/a
11V TDFC N/A 450 2440 3100 1970 2430 2610 2940 2870 3000 2700 2690 2670 2980 n/a n/a n/a n/a
11V TDFC N/A 500 2530 3040 2070 2420 2760 3090 3130 3470 2980 3340 2820 3150 n/a n/a n/a n/a
Installation Mechanical
