AC-SVX003A-EN
41
Table 18. Point weights - I-P (lb) (continued)
Cond
(a)
Free-
Cooling
(b)
Pump
(c)
Unit
Size
Mounting Location
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
11V TDFC N/A 550 2530 3040 2070 2420 2760 3090 3130 3470 2980 3340 2820 3150 n/a n/a n/a n/a
Standard Length Units with Options Box
(d)
11V NONE N/A 380 2330 3070 1870 1870 2190 2170 2290 2070 2240 1970 2980 2470 n/a n/a n/a n/a
11V NONE N/A 450 2330 3070 1870 1870 2190 2170 2290 2070 2240 1970 2980 2470 n/a n/a n/a n/a
11V NONE N/A 500 2370 3070 1920 1920 2310 2350 2510 2580 2450 2640 3060 2730 n/a n/a n/a n/a
11V NONE N/A 550 2370 3070 1920 1920 2310 2350 2510 2580 2450 2640 3060 2730 n/a n/a n/a n/a
11V TDFC N/A 380 2710 3670 2080 2610 2650 3000 2960 3050 2890 2810 3230 3240 n/a n/a n/a n/a
11V TDFC N/A 450 2710 3680 2080 2610 2660 3000 2960 3050 2890 2810 3230 3240 n/a n/a n/a n/a
11V TDFC N/A 500 2790 3620 2130 2580 2730 3040 3120 3460 3110 3400 3370 3400 n/a n/a n/a n/a
11V TDFC N/A 550 2790 3620 2130 2580 2740 3030 3130 3460 3110 3400 3370 3400 n/a n/a n/a n/a
Extended Length Units
(e)
4V N/A N/A 150 2270 2030 2240 2050 1890 2090 740 1010 n/a n/a n/a n/a n/a n/a n/a n/a
4V N/A N/A 165 2270 2030 2240 2060 1900 2090 750 1020 n/a n/a n/a n/a n/a n/a n/a n/a
4V N/A N/A 180 2150 1940 2390 2250 2430 2780 780 980 n/a n/a n/a n/a n/a n/a n/a n/a
5V NONE N/A 180 2190 1970 2320 2210 2340 2590 770 970 n/a n/a n/a n/a n/a n/a n/a n/a
5V NONE N/A 180 2150 1940 2390 2250 2430 2780 780 980 n/a n/a n/a n/a n/a n/a n/a n/a
5V NONE N/A 200 2150 1940 2390 2250 2440 2790 780 980 n/a n/a n/a n/a n/a n/a n/a n/a
5V NONE N/A 225 2260 1990 2660 2470 2700 3160 820 1090 n/a n/a n/a n/a n/a n/a n/a n/a
5V NONE N/A 250 2260 1990 2680 2490 2720 3180 820 1090 n/a n/a n/a n/a n/a n/a n/a n/a
5V TDFC N/A 165 2390 2220 2500 2470 2230 2580 2040 2630 n/a n/a n/a n/a n/a n/a n/a n/a
5V TDFC N/A 180 2350 2220 2980 3040 2880 3290 1120 1560 n/a n/a n/a n/a n/a n/a n/a n/a
5V DFC1 N/A 165 3070 2990 2740 2650 2560 2540 990 2580 790 910 n/a n/a n/a n/a n/a n/a
5V DFC1 N/A 180 3080 3000 2780 2690 2620 2580 1010 2620 800 910 n/a n/a n/a n/a n/a n/a
5V DFC2 N/A 165 2950 2850 2620 2470 1860 2480 1820 2700 1230 1640 n/a n/a n/a n/a n/a n/a
5V DFC2 N/A 180 2960 2870 2670 2510 1910 2530 1860 2740 1230 1640 n/a n/a n/a n/a n/a n/a
6V NONE N/A 200 2590 2380 2360 2290 2040 2250 740 860 620 700 n/a n/a n/a n/a n/a n/a
6V NONE N/A 225 2810 2480 2620 2470 2240 2520 790 970 610 750 n/a n/a n/a n/a n/a n/a
6V NONE N/A 250 2850 2520 2700 2550 2320 2590 810 990 600 730 n/a n/a n/a n/a n/a n/a
6V NONE N/A 275 2860 2530 2720 2560 2340 2610 810 990 600 730 n/a n/a n/a n/a n/a n/a
6V TDFC N/A 200 2700 2620 2720 2690 2690 2710 1060 2070 1010 980 n/a n/a n/a n/a n/a n/a
6V TDFC N/A 225 2910 2760 2960 2760 2880 2660 1120 2620 1030 960 n/a n/a n/a n/a n/a n/a
Installation Mechanical
