24
AC-SVX001A-EN
NNOOTTIICCEE
EEqquuiippmmeenntt DDaammaaggee!!
MMoovviinngg tthhee cchhiilllleerr uussiinngg aa ffoorrkk lliifftt ccoouulldd rreessuulltt iinn
eeqquuiippmmeenntt oorr pprrooppeerrttyy--oonnllyy ddaammaaggee..
DDoo nnoott uussee aa ffoorrkk lliifftt ttoo mmoovvee tthhee cchhiilllleerr!!
IImmppoorrttaanntt::
• See unit nameplate and/or unit
submittal for total shipping weight.
• See following figures for unit lifting
configuration.
• See Dimensions and Weights chapter,
or unit submittal, for lifting point
locations.
• See Center of Gravity section for more
information.
Figure 7. 4–point lift configuration — 150, 160, 180 ton units
96” (2438mm) Spreader Bar
Lifting Location 3
(Lifting location 4
located on other side of unit)
Lifting Location 1
(Lifting location 2
located on other side of unit)
Control Panel
