Trane Ascend ACR Series User Manual

AC-SVX001A-EN
25
Figure 8. 6–point lift configuration — 200, 225, 250, 275 ton units
96” (2438mm) Spreader Bar
96”
(2438mm)
Spreader Bar
Lifting Location 1
(Lifting location 2
located on other side of unit)
Lifting Location 3
(Lifting location 4
located on other side of unit)
Lifting Location 5
(Lifting location 6
located on other
side of unit)
Control Panel
Figure 9. 8–point lift configuration — 300 ton units
96” (2438mm) Spreader Bar
Qty 2
Lifting Location 1 (Lifting location 2 located on other side of unit)
Lifting Location 3
(Lifting location 4
located on other side of unit)
Lifting Location 5
(Lifting location 6
located on other side of unit)
Lifting Location 7
(Lifting location 8
located on other
side of unit)
Control Panel
IInnssttaallllaattiioonn MMeecchhaanniiccaall
