BAS-SVX44A-EN 21
Power, System Tests, and Software Reset
When exiting System Test Mode, the system will run a software reset and return to the
Operating Home screen. If test 15=1, the software reset will be preceded by a Power-up Test
(refer to Table 6, p. 22).
Figure 17. Configuration button and system test mode display
Configuration Button
System Test Mode Display
System
Test
Number
Save and move to the next higher or
previous lower System Test Number
Increment or Decrement
the Test Value
Save and move
to next higher
System Test
Number
Test
Value
Test icon blinks
