ASHRAE Guideline 3 Report
8 CVHE-CLD-1A
Saturated Evap Temperature/Evap Refrigerant
Pressure
Evaporator Approach Temp.
Evaporator Entering/Leaving Water Pressure
The following will be displayed only if the low
pressure (< or = to 150 psig) Differential Water
Pressure Sensor Option is Installed.
Evaporator Differential Water Pressure
The following will be displayed only if the Differential
Water Pressure Sensor Option is Installed.
Evaporator Water Flow
The following is displayed only if the Differential
Water Sensing Option is installed.
The possible values for units are “gpm” or “lpm.”
Chilled Water Flow Switch Status
The following will be displayed only if the Differential
Water Sensing Option is not installed. This screen
displays the status of the chilled water flow switch
status at the input to the UCM.
Possible values for [y] are: Flow Switch is Open/No
Flow or Flow Switch is Closed/Flow.
Chiller Tons
The following will be displayed only if the Differential
Water Sensing Option is installed.
The possible values for units are “Tons” or “KW.”
Cond Entering and Leaving Water Temps
Dashes will be displayed for condenser entering or
leaving water temperature if the corresponding input
is open or shorted.
Saturated Cond Temperature/Cond Refrigerant
Press
Condenser Approach Temp.
Condenser Entering/Leaving Water Pressure
The following will be displayed only if the low
pressure (< or = to 150 psig) Differential Water
Pressure Sensor Option is Installed.
Condenser Differential Water Pressure
The following will be displayed only if the Differential
Water Pressure Sensor Option is Installed.
Saturated Evap Rfgt Temp: xxx.x f/c
Evap Rfgt Pressure: xxx.x psig
Evaporator Approach Temp.: xx.x f/c
Press (Next)(Previous) To Continue
Evap Entering Water Pressure:xx.x psid/kPa
Evap Leaving Water Pressure: xx.x psid/kPa
Evap Differential Wtr Press: xx.x psid/kPa
Press (Next)(Previous) To Continue
Approx Evaporator Water Flow:xxx.x gpm/lpm
Press (Next)(Previous) To Continue
Chilled Water Flow Switch Status:
[y]
Approximate Chiller Capacity: xxxx Tons/KW
Press (Next)(Previous) To Continue
Cond Entering Water Temp: xxx.x f/c
Cond Leaving Water Temp: xxx.x f/c
Saturated Cond Temp: xxx.x f/c
Cond Rfgt Pressure: xxx.x psig
Condenser Approach Temp.: xx.x f/c
Press (Next)(Previous) To Continue
Cond Entering Water Pressure:xx.x psid/kPa
Cond Leaving Water Pressure: xx.x psid/kPa
Cond Differential Wtr Press: xx.x psid/kPa
Press (Next)(Previous) To Continue
To Next Page
