Machine Configuration
48 CVHE-CLD-1A
This option screen applies to both the Evap and
Cond differential water pressure sensors for both
systems less than or equal to 150 psig (Sensors at
the Chiller Module) and systems greater than 150
psig (Sensors at the Options Module).
External Analog Input Type Selection,
4-20 ma/2-10 VDC
Possible values for status are: 4-20ma (Factory
Default) and 2-10 VDC.
Tracer Option
Possible values for status are: Installed and Not
Installed (Factory Default).
TCI Option
Possible values for status are: Installed and Not
Installed (Factory Default).
Printer Option
Possible values for status are: Installed and Not
Installed (Factory Default).
Duplex Control Module (DCM) Option
Possible values for status are: Installed and Not
Installed (Factory Default).
IGV Output Type
Possible values for Y are: Stepper Motor (Factory
Default) and Pulsed.
If Inlet Guide Vane Output is set to Pulsed and the
Hot Gas Bypass Option is currently set to Installed,
the Hot Gas Bypass Option will be set to Not
Installed and the following will be displayed for 3 sec
to indicate the change.
Oil Pressure Protection
Possible values for [status] are: Transducer (Factory
Default), and Diff Switch, Xducer & Switch.
Programmable Analog Output
Possible values of [Output] are:
External Setpoint Inputs: [type]
Press (+)(-) to Change Setting
Tracer Option:
[status]
Press (+)(-) to Change Setting
TCI Option: [status]
Press (+)(-) to Change Setting
Printer Option: [status]
Press (+)(-) to Change Setting
DCM Option: [status]
Press (+)(-) to Change Setting
Inlet Guide Vane Output: [Y]
Press (+)(-) to Change Setting
Hot Gas Bypass Option
Has Been Set to Not Installed
Oil Pressure Protection:
[status]
Press (+)(-) to Change Setting
Program Analog Output: [Output]
Press <+> <-> To Change Setting
Not Used % Cond Pres
% RLA Refrig Diff Pres
