Operator Settings
24 CVHE-CLD-1A
Range of values is 0 to 10 min. Factory Default is 5
min.
Chilled Water Setpoint Source
If the Tracer Option is installed, the word “Default”
will appear in front of the setpoint source.
Possible values of [source] are: Front Panel (Factory
Default) and External Source (This choice shows up
only if the External Chilled Water Setpoint is Installed
at the Machine Configuration menu.).
Note: There is a Tracer installed screen in the
Machine configuration menu. If Tracer does not
choose to write a setpoint then the “default” setpoint
source is used, e.g. Front Panel.
Current Limit Setpoint Source
If the Tracer Option is installed, the word “Default”
will appear in front of the setpoint source.
Possible values of [source] are: Front Panel (Factory
Default), and External Source. (This choice shows up
only if the External Current Limit Setpoint is Installed
at the Machine Configuration menu.)
Note: There is a Tracer installed screen in the
Machine configuration menu. If Tracer does not
choose to write a setpoint then the “default” setpoint
source is used, e.g. Front Panel.
Hot Water Setpoint Source
If the Tracer Option is installed, the word “Default”
will appear in front of the setpoint source.
Possible values of [source] are: Front Panel (Factory
Default) and External Source (This choice shows up
only if the External Hot Water Setpoint is Installed at
the Machine Configuration menu.)
Note: There is a Tracer installed screen in the
Machine configuration menu. If Tracer does not
choose to write a setpoint then the “default” setpoint
source is used, e.g. Front Panel.
Ice Termination Setpoint Source
The following will be displayed only if the Ice Building
Option is installed.
If the Tracer Option is installed, the word “Default”
will appear in front of the setpoint source.
Possible values of [source] are: Front Panel (Factory
Default).
Note: There is a Tracer installed screen in the
Machine configuration menu. If Tracer does not
choose to write a setpoint then the “default” setpoint
source is used, e.g. Front Panel.
Outdoor Air Temperature Source
If the Tracer is installed the Tracer Outdoor Air
Temp. is both used and displayed. If no Tracer is
installed the chiller module outdoor air temperature
sensor is used. If no sensor is installed, dashes are
displayed on the display of Outdoor Air Temperature.
Setpoint Source Override
Possible values of [source] are: “None” (Factory
Default), “Use Front Panel Setpoints”, “Override
Tracer, and Use Default Setpoints” (Available only if
Tracer Option installed).
[Default] Chilled Water Setpoint Source:
[source]
[Default] Current Limit Setpoint Source:
[source]
[Default] Hot Water Setpoint Source:
[source]
[Default] Ice Termination Setpoint Source:
[source]
Setpoint Source Override:
[source]
