Trane CVHG Information Manual

Compressor Report
18 CVHE-CLD-1A
Compressor Report
The Compressor Report Group sequence is as
follows.
Report Heading
Differential Oil Pressure, Oil Temperature
The possible value for [units] is “psid” or “kPa”
dependent upon whether English or SI units are
selected.
Discharge Oil Pressure, Oil Tank
Pressure
AF Compressor Speed Command
The following is displayed only if the Starter Type is
“Adaptive Frequency” or “AFDB” or the Compressor
Power Source is Engine/Generator and Adaptive
Speed Control Algorithm is Enabled.
Range of values is 2520 to 3600 rpm in increments of
1 rpm. Factory default is 3600 rpm.
AF Boundary Pressure Coefficient/AF
Press. Coefficient
The following is displayed only if the Starter Type is
“Adaptive Frequency” or “AFDB” or the Compressor
Power Source is Engine/Generator and Adaptive
Speed Control Algorithm is Enabled.
Note: This is a Report only for Troubleshooting
purposes.
AF Re-Optimization Timer Time
Remaining
The following is displayed only if the Starter Type is
“Adaptive Frequency” or “AFDB” or the Compressor
Power Source is Engine/Generator and Adaptive
Speed Control Algorithm is Enabled.
Note: This is a Report only for Troubleshooting
purposes.
Inlet Guide Vane Position
This screen does not appear if “Inlet Guide Vane
Output” is set to “Pulsed.”
Compressor Hours, Starts & Amps
Press (Next)(Previous) To Continue
Differential Oil Pressure: xxx.x [units]
Oil Tank Temperature: xxx.x f/c
Discharge Oil Pressure: xxx.x psig
Oil Tank Pressure: xxx.x psig
AF Compressor Speed Command: xx Hz
AF Compressor Speed Command: xxxx RPM
AF Boundary Press Coefficient: x.xxx
AF Pressure Coefficient: x.xxx
AF Re-Optimization Time Remaining:xx:xxHrs
Press (Next) (Previous) to Continue
Inlet Guide Vane Position xxx.x % Open
Inlet Guide Vane Position xx.x degrees
