Trane CVHG Information Manual

Machine Configuration
44 CVHE-CLD-1A
Table 3
CT Factor = (Motor RLA/CT Meter Scale Rating) X 139
Line CT Part
No. Ext
Line CT
Ratio
CT Ter.
Conn
No. of Prim.
Turns RLA Ranges
Meter
Scale
X13580272 -01 50:5 X1 to X2 3 8.0 – 11.9 16.7
2 12.0 – 17.9 25.0
-02 75:5 2 18.0 – 23.9 37.5
-01 50:5
1
24.0 – 35.9 50
-02 75:5 36.0 – 47.9 75
X13580271 -01 100:5 48.0 – 72.0 100
X13580048 150:5 72.0 – 86.3 150
180:5 X1 to X3 86.4 – 95.9 180
200:5 X1 to X4 96.0 – 119.9 200
-02 250:5 X1 to X2 120.0 – 143.9 250
300:5 X1 to X3 144.0 – 167.9 300
350:5 X1 to X4 168.0 – 191.9 350
-03 400:5 X1 to X2 192.0 – 239.9 400
500:5 X1 to X3 240.0 – 287.9 500
600:5 X1 to X4 288.0 – 335.9 600
-04 700:5 X1 to X2 336.0 – 383.9 700
800:5 X1 to X3 384.0 – 479.9 800
1000:5 X1 to X4 480.0 – 575.9 1000
-05 1200:5 X1 to X2 576.0 – 719.9 1200
1500:5 X1 to X3 720.0 – 863.9 1500
X13580047 -01 1800:5 X1 to X2 864.0 – 1007.9 1800
2100:5 X1 to X3 1008.0 – 1199.9 2100
2500:5 X1 to X4 1200.0 – 1800 2500
-02 1000:5 X1 to X2 480.0 – 575.9 1000
1200:5 X1 to X3 576.0 – 719.9 1200
1500:5 X2 to X4 720.0 – 863.9 1500
